Descrição
– Taxa de transferencia: 11Mbps (11b mode)/54Mbps (11g mode)/300Mbps (802.11n draft).
– Padrões:
IEEE 802.11b/802.11g/802.11n draft (Wireless).
IEEE 802.3/802.3u (Wired).
– Alcance de operação: 100M indoor e 400M outdoor.
– Acesso a Internet: Connect to Broadband (Cable or xDSL) modem or Ethernet backbone for Internet Surfing
– Conexões WAN: Dynamic IP, Static IP, PPPoE, PPTP, L2TPSupport MAC Clone
– Routing: Static IP Routing.
– RIP version 1 (RFC 1058) and version 2 (RFC 1723).
– IP Management: NAT (Network Address Translation).
– NAPT (Network Address and Port Translation).
– DHCP (Dynamic Host Configuration Protocol) Server/Client.
– Support VPN pass through ¡V IPSec, PPTP, L2TP.
– Support Virtual server / Port Trigger / Port Forward.
– Support Virtual DMZ host.
– Support DNS Proxy.
– Support Dynamic DNS.
– Support UPnP (Internet Gate Device).
– Security Management:
64/128-bit WEP Data Encryption.
WPA, WPA2 (802.11i) security.
ACL (MAC Access Control List).
WDS (Wireless Distribution System).
WPS (Wi-Fi Protected Setup).
PAP/CHAP/MS-CHAP/MS-CHAPv2 authentication.
RADIUS Server (IEEE 802.1x).
Password Protected Configuration.
– Firewall:
MAC filter.
IP filter.
URL blocking.
NAT Protection.
Hacker pattern detection (Port Scan , Syn Flood …etc).
– Gerenciamento:
Web-based GUI Configuration / Management
Telnet remote management / Web Remote Login
Software Upgrade through Web
Suporte a NTP update
Suporte a System Log
Suporte a Config setting Backup/Restore/Reset Default.
– Interface
LAN x 4, WAN x 1
– Antenas: 3.
– Frequências:
2.400~2.4835GHz
– Receiver Sensitivity
IEEE 802.11b: -84 dBm (Typical).
IEEE 802.11g: -60dBm (Typical).
IEEE 802.11n: 20Mhz -87dBm / 40Mhz -66dBm (Typical).
– Transmit Output Power
11b: 19±11 dBm.
11g: 15±11 dBm.
11n: 17±11 dBm.
