Descrição
– CPU
Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1155 package
L3 cache varies with CPU
– Chipset
Intel® H61 Express Chipset
– Memória
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
Dual channel memory architecture
Support for DDR3 2200(OC)/1333/1066/800 MHz memory modules
Support for non-ECC memory modules
Support for Extreme Memory Profile (XMP) memory modules
– Gráficos Onboard
Integrated Graphics Processor:
1 x D-Sub port
1 x HDMI port, supporting a maximum resolution of 1920×1200
– Áudio
Realtek ALC887 audio codec
High Definition Audio
2/4/5.1/7.1-channel
– LAN
1 x Realtek 8111F chip (10/100/1000 Mbit)
– Slots de Expansão
1 x PCI Express x16 slot, running at x16
3 x PCI Express x1 slots
– Interface de Armazenamento
4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
– USB
Up to 10 USB 2.0/1.1 ports (6 ports on the back panel, 4 ports available through the internal USB headers)
– Conectores Internos I/O
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
2 x USB 2.0/1.1 headers
1 x Clear CMOS jumper
– Conectores Painel Traseiro
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x HDMI port
6 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
– Controlador I/O
iTE I/O Controller Chip
– Monitoramento H/W
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
– BIOS
2 x 32 Mbit flash
Use of licensed AMI EFI BIOS
Support for DualBIOS™
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a
– Características Exclusivas
Support for @BIOS
Support for Q-Flash
Support for Xpress Recovery2
Support for EasyTune
Support for ON/OFF Charge
– Form Factor
Micro ATX Form Factor; 24.4cm x 17.4cm
