Descrição
CPU
Socket FM1 for AMD A series
E Series
Athlon Quard-core
Athlon Dual-core
Sempron Dual-core processors
CHIPSET
AMD A75 FCH
MEMORY
Support Dual-channel DDR3 1333/1600/1866* memory architecture
2 x 240-pin DDR3 DIMM socket support up to 32GB per one DIMM support 16GB
EXPANSION SLOT
1 x PCI Express x16 slot
2 x PCI Express x1 slots
1 x PCI slot
STORAGE
Support by AMD A75
6 x Serial ATA 6.0Gb/s devices
RAID0, RAID1, RAID10 configuration
AUDIO
Realtek ALC662 6-channel audio
Compliant with HD audio specification
LAN
Realtek 8111E Gigabit LAN Fast Ethernet Controller
REAR PANEL I/O
6 x USB 2.0 ports
2 x USB 3.0 ports compatible to both USB 3.0/2.0 devices (blue)
1 x PS/2 keyboard & PS/2 mouse connectors
1 x DVI connector(optional)
1 x HDMI Port
1 x D-sub(VGA)
1 x RJ45 LAN connector
1 x Audio port
INTERNAL I/O CONNECTORS & HEADERS
1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX 12V connector
1 x 4-pin CPU_FAN connector
1 x 3-pin SYS_FAN connector
2 x USB 2.0 headers support additional 4 USB 2.0 Ports
1 x USB 3.0 header supports additional 2 USB 3.0 Ports
6 x Serial ATA 6Gb/s connectors
1 x COM header
1 x LPT header
1 x Front panel audio header
1 x Case Open header
1 x Speaker header
1 x Clear CMOS header
1 x SPDIF out header
SYSTEM BIOS
AMI BIOS with 16Mb SPI Flash ROM
Supports Multi-language BIOS
Supports ECS M.I.B III Utility
Supports eBLU
Supports eDLU
Supports eSF
Support EZ Charger
FORM FACTOR
Micro-ATX Size (24,40cm x 20,00cm)
