Descrição
– Processador
Intel Socket 775 Core 2 Quad/Core™2 Extreme/Core™2 Duo.
Pentium® D/Pentium® 4/Celeron E1000 Series and Celeron 400 Series Processors
Suporta a próxima geração de CPUs Intel® 45nm
Preparada para a Tecnologia Intel® Hyper-Threading
Suporta a Tecnologia Enhanced Intel® SpeedStep® Technology (EIST)
– Chipset
G31 /ICH7
– Front Side Bus
1600(O.C)/1333/1066/800/533 MHz
– Memória
2 x DIMM
Máximo de 4 GB
DDR2 1066/800/667 Non-ECC
Un-buffered Memory
– Arquitetura da memória
Dual Channel
– Slots de Expansão
1 x PCIe x16
1 x PCIe x1
1 x PCI
– VGA
Integrated Intel Graphics Media Accelerator (Intel® GMA 3100)
Resolução Máxima: 2048x1536X32bpp
– Armazenamento
Southbridge
UltraDMA 100/66/33 1 x
2 xSATA 3 Gb/s ports
– LAN
RTL8102EL 10/100M
– Áudio
ALC662 6 -Channel High-Definition Audio CODEC
– USB
portas USB 2.0 (4 ports at mid-board, 4 ports at back panel) 8
– ASUS AI Lifestyle Features
ASUS Quiet Thermal Solution:
ASUS Q-Fan
ASUS EZ DIY:
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2
– Painel traseiro I/O Portas
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x RJ45 port
4 x USB 2.0/1.1
1 x COM port
6 Channel Audio I/O
– Conectores Internos I/O
1 x Conector de Audio High Definition (Front Panel)
1 x Conector IDE
1 x Conector CD audio-in
1 x CPU fan connector
1 x Conector Chassis fan
2 x Conectores SATA
2 x Conectores USB 2.0 para 4 Portas adicionais USB 2.0
1 x Conector de Força 24-pin EATX
1 x Conector de força 4-pin x ATX 12V
1 x Conector System panel
– BIOS
8 Mb Flash ROM
AMI BIOS
PnP
DMI2.0
WfM2.0
SM BIOS 2.5
– Gerenciamento
WOL,PXE,RPL,WOR ,PME Wake Up
